New!
3-lamp 3-phase models reduce the number of heaters required and
can be mounted at greater heights.
|
SolarbeamTM
Universal Quartz Lamp Infrared Heaters.
Save up to 20% on electric heating bills compared to forced air or convection systems!
Aitken's all weather quartz lamp heaters save up to 20% on electric heating bills compared
to forced air or convection systems! Aitken quartz lamp infrared heaters are available in universal
"all-weather" models for indoor or outdoor installations. Two types of lamps are also available
(push/pull spring-loaded silver tipped contact for easy snap-in connection) or "pigtail" for more
positive connections (lamps cannot fall out).
Minimum mounting height - 10 feet. Where ceilings
are under 10 feet... or other reasons seem to dictate
less than 10-foot mounting height, consult a qualified
infrared authority for advice. Do not install closer
than 24 inches to vertical surface. Can be stem mounted
to any supporting surface. For supply connections, use
wire suitable for at least 75°C (167°F). |
Quartz Lamps
|
Model
|
Watts
|
Volts
|
Amps
|
|
Butt Socket QH / SQH |
|
P70010
|
500
|
120
|
4.17
|
|
P70013
|
1600
|
208
|
7.69
|
|
P70014 |
1600
|
240
|
6.67
|
|
P70015 |
1600
|
277
|
5.78
|
|
P70016
|
2500
|
480
|
5.21
|
|
Pig Tail QHL / SQHL |
|
P80005
|
500
|
120
|
4.17
|
|
P80208
|
1600
|
208
|
7.69
|
|
P80240
|
1600
|
240
|
6.67
|
|
P80277
|
1600
|
277
|
5.78
|
|
P80480
|
2500
|
480
|
5.21
|
Quartz Heater Accessories
|
Recessing
Frames |
|
* PA 9700 |
For 3200 watt units |
|
* PA 9700-1 |
For 5000 watt units |
|
Wire Guards |
|
P54580-2 |
Fits 1000 watt double lamp unit |
|
P54580 |
Fits 3200 watt double lamp unit |
|
P54580-1 |
Fits 5000 watt double lamp unit |
|
P54581 |
Fits 1600 watt single lamp unit |
|
P54581-1 |
Fits 2500 watt single lamp unit |
|
54583-1 |
Fits 4800 watt |
|
54583 |
Fits 7500 watt |
|
|
